FIREESCAPE DOUBLE EXTENSION LADDERS
Manufactured using our standard rivetted turss method of construction. The range of double extension ladders are based upon the top two sections of Triple Extension Ladders. There are four ladders in the standard range with extended lengths of 5.5 M to 10.5 M. The method of construction used lends itself to flexibility of manufacture and ladder can be custom made to suit the needs of user either in closed or extended length. As an option the top section of all double extension ladders can be removed using quick release stops.
DOUBLE EXTENSION LADDERS - 3 PERSONS RESCUE
| Model No. | Extended Length | Closed Length | Height | Width | Weight In Kg | No. Of Steps | No. Of Support |
|---|---|---|---|---|---|---|---|
|
6.1 DE |
6.1 mtr (20 feet) |
3.7 mtr (12 feet) |
220mm |
560mm |
36 kg |
12 |
4 |
|
7.5 DE |
7.5 mtr (24.6 feet) |
4.8 mtr (15.7 feet) |
220mm |
560mm |
44 kg |
15 |
5 |
|
10.5 DE |
10.5 mtr (34.4 feet) |
6.2 mtr (20.3 feet) |
220mm |
560mm |
56 Kg |
20 |
5 |
|
13.5 DE |
13.5 mtr (44.4 feet) |
8 mtr (26.2 feet) |
220mm |
560mm |
74.8 kg |
26 |
8 |
FIREESCAPE TRIPLE EXTENSION LADDER
Fireescape Triple Extension Ladders are available mainly in three sizes. All are made to the same standards of construction with the 10.5 M & 15 M ladders, having a deeper stile section for added rigidity. On the 13.5 M & 15 M ladders a stabilizer bar with adjustable feet is fitted to the base of the ladder to cope with uneven ground. Poles are also attached to the head of the bottom section for ease of handing and to give additional stability when needed.
TRIPLE EXTENSION LADDERS - 3 PERSONS RESCUE
| Model No. | Extended Length | Closed Length | Height | Width | Weight In Kg | No. Of Steps | No. Of Support |
|---|---|---|---|---|---|---|---|
|
7.5 TE |
7.5 mtr (24.6 feet) |
3.5 mtr (11.4 feet) |
290mm |
690mm |
55 kg |
11 |
4 |
|
10.5 TE |
10.5 mtr (34.4 feet) |
4.6 mtr (15 feet) |
290mm |
690mm |
70 kg |
15 |
5 |
|
13.5 TE |
13.5 mtr (44.4 feet) |
5.8 mtr (19 feet) |
290mm |
690mm |
116 Kg |
18 |
5 |
